RPLiDAR A1M8 360 Degree Laser Scanner Kit - 12M Range
৳21,700
RPLiDAR S3 - 40m range, 2D point cloud map, 32KHz sampling, 0.1125° angular resolution, 80000 lux light resistance, IP65, high safety for human eye
৳82,000
The RPLiDAR S3M1 is a high-performance 2D laser scanner developed by SLAMTEC, offering a 40-meter range and 32,000 samples per second sampling rate. With an angular resolution of 0.1125°, it delivers precise 2D point cloud mapping suitable for both indoor and outdoor applications. Its IP65 rating ensures durability in various environments, while the Class 1 laser safety certification guarantees safe operation.
The RPLiDAR S3M1 utilizes Time-of-Flight (ToF) technology to perform 360° laser scanning, capturing detailed spatial data for various applications such as robotics, mapping, and environment modeling. Key features include:
Distance Range: 0.05 to 40 meters (white objects)
Angular Resolution: 0.1125°
Sampling Rate: 32,000 samples per second
Scan Frequency: 10 Hz (600 rpm)
Light Resistance: Operates effectively under sunlight up to 80,000 lux
Safety: IEC-60825 Class 1 laser safety standard
Communication Interface: TTL UART
Power Supply: 5V DC
This scanner is ideal for applications requiring precise and reliable 2D mapping, including autonomous navigation, SLAM (Simultaneous Localization and Mapping), and environmental modeling.
