Onkon-4040 Writing and Drawing Machine Pen Plotter
৳20000
The Onkon-4040 XY Plotter available at BDTronics is a fully assembled 2D drawing bot designed for precision writing and drawing on various flat surfaces. Ideal for applications such as pen writing, pencil sketching, and CAD drawings, this machine offers versatility and ease of use.
Key Features
Drawing Area: 34x30 cm (13.5" x 11.8")
Axis Length: 400mm (X and Y axes)
Writing Angle: Adjustable from 35° to 90°
Weight: Approximately 4kg
Control Board: Arduino UNO with GRBL shield
Drive System: Belt drive
Stepper Motor: Twotress Nema17 17HS8401
Motor Driver: DRV8825/TMC2208
Supported Writing Tools: Pencil, ballpoint pen, marker, gel pen, etc. (pen holder is adjustable and replaceable)
Supported Software: Universal Gcode Sender, Inkspace
Package Includes
1 pcs Onkon-4040 Drawing Bot
1 pcs Instruction manual
1 pcs 4.5A Power Adapter
1 pcs Gel Pen
1 pcs USB Cable
1 pcs USB Flash Disk (Software)
