UNI-T UTP3315TFL-II DC Regulated Power Supply
৳11,270
The UNI-T UTP3315TFL-II is a high-quality, single-channel linear DC power supply designed for precision electronics work. With an output range of 0–30V and 0–5A, it delivers up to 150W of clean, stable power, making it ideal for testing and powering a variety of electronic components and circuits.
| Feature | Details |
|---|---|
| Output Voltage | 0–30V |
| Output Current | 0–5A |
| Maximum Output Power | 150W |
| Load Regulation | CV ≤ 0.01% + 5mV, CC ≤ 0.1% + 10mA |
| Ripple & Noise | ≤2mVrms |
| Resolution | Voltage: 10mV, Current: 1mA |
| Setting Accuracy | Voltage: <0.5% + 20mV, Current: <0.5% + 10mA |
| Display | Dual 4-digit LED (voltage and current) |
| Protection Features | Overload, short-circuit, and reverse polarity protection |
| MTBF | ≥2000 hours |
| Dimensions | 105mm × 165mm × 249mm |
| Weight | 4 kg |
| Power Input | 110V/220V ±5%, 50/60Hz |
