GX16 Plug 3 Pin Male Female Aviation Connector Dual Ports
৳282
The GX16 2-Pin Aviation Connector is a compact, durable, and secure metal connector designed for stable electrical connections in industrial and hobby electronics. It includes one male plug and one female socket, both featuring a threaded screw-lock mechanism to prevent accidental disconnection during operation or movement. Ideal for custom wiring, this connector is commonly used in applications such as sensors, LED lighting, automation systems, CNC machines, and 3D printers.
| Feature | Details |
|---|---|
| Product Type | GX16 Aviation Connector (Male + Female) |
| Pin Count | 2 Pins |
| Connection Type | Solder Terminals |
| Locking Mechanism | Threaded Screw Lock |
| Panel Mounting | Up to 8.5mm thickness |
| Material | Metal Body |
| Color | Silver |
| Male Dimensions | 35.3mm (Length) × Ø18.5mm (Diameter) |
| Female Dimensions | 20.8mm × 21.6mm |
| Rated Current | 7A |
| Rated Voltage | 125V |
| Contact Resistance | ≤ 0.005Ω |
| Insulation Resistance | ≥ 1,500 MΩ |
| Operating Temperature | -50°C to +70°C |
| Applications | Sensors, LED Lighting, Automation Systems, CNC Machines, 3D Printers |
